Eight models, fully specified
From 40 litres a day for a small household, to 5,000 litres for a full industrial site. Every specification below is the manufacturer’s own, measured at 32°C and 80% relative humidity.
- 8
- Approved models
- 40 — 5,000L/day
- Daily output range
- 0.24 — 0.44kWh/L
- Energy consumption range
- 3
- Series, by size of site
Series Premium
MEGHDOOT PREMIUMA compact, self-contained series for homes, apartments, small offices and laboratories. It combines generation and purification in a single unit that produces mineral-rich water ready to drink.
40 — 250L/day
Classic DLXClassic DLX40L/day0.7kWSmall family · office · clinic
- Daily output (maximum)
- 40L
- Electrical supply
- 230V 1ø
- Power consumption
- 0.7kW
- Energy per litre
- 0.42kWh/L
- Refrigerant
- R134a
- Tank capacity
- 24L
- Dimensions (L × W × H)
- 518 × 515 × 1475mm
- Floor area
- 0.27m²
- Weight
- 102kg
- Measurement conditions
- 32°C · 80%relative humidity
- Filtration
- Multi-stage + minerals
Classic PlusClassic Plus60L/day1.1kWMedium family · medium office
- Daily output (maximum)
- 60L
- Electrical supply
- 230V 1ø
- Power consumption
- 1.1kW
- Energy per litre
- 0.44kWh/L
- Refrigerant
- R134a
- Tank capacity
- 25L
- Dimensions (L × W × H)
- 700 × 550 × 950mm
- Floor area
- 0.39m²
- Weight
- 100kg
- Measurement conditions
- 32°C · 80%relative humidity
- Filtration
- Multi-stage + minerals
PremiumPremium150L/day2.0kWVilla · laboratory · small company
- Daily output (maximum)
- 150L
- Electrical supply
- 230V 1ø
- Power consumption
- 2.0kW
- Energy per litre
- 0.32kWh/L
- Refrigerant
- R407C
- Tank capacity
- 60L
- Dimensions (L × W × H)
- 960 × 790 × 1250mm
- Floor area
- 0.76m²
- Weight
- 180kg
- Measurement conditions
- 32°C · 80%relative humidity
- Filtration
- Multi-stage + minerals
Premium PlusPremium Plus250L/day3.4kWLarge villa · small residential building
- Daily output (maximum)
- 250L
- Electrical supply
- 440V 3ø
- Power consumption
- 3.4kW
- Energy per litre
- 0.33kWh/L
- Refrigerant
- R407C
- Tank capacity
- 100L
- Dimensions (L × W × H)
- 1000 × 850 × 1505mm
- Floor area
- 0.85m²
- Weight
- 260kg
- Measurement conditions
- 32°C · 80%relative humidity
- Filtration
- Multi-stage + minerals
Series Magnum
MEGHDOOT MAGNUMThe largest pre-built series, designed for the demands of residential complexes, large facilities and laboratories. It uses multi-stage purification with an ozonator and a bespoke mineral dosing system.
500 — 1,000L/day
MagnumMagnum500L/day5.5kWSmall hotel · office building · school
- Daily output (maximum)
- 500L
- Electrical supply
- 440V 3ø
- Power consumption
- 5.5kW
- Energy per litre
- 0.26kWh/L
- Refrigerant
- R407C
- Tank capacity
- 300L
- Dimensions (L × W × H)
- 1150 × 1820 × 1200mm
- Floor area
- 2.09m²
- Weight
- 380kg
- Measurement conditions
- 32°C · 80%relative humidity
- Filtration
- Multi-stage + minerals
Magnum PlusMagnum Plus1,000L/day11.0kWHotel · residential complex · hospital
- Daily output (maximum)
- 1,000L
- Electrical supply
- 440V 3ø
- Power consumption
- 11.0kW
- Energy per litre
- 0.26kWh/L
- Refrigerant
- R407C
- Tank capacity
- 500L
- Dimensions (L × W × H)
- 1200 × 1500 × 1650mm
- Floor area
- 1.8m²
- Weight
- 450kg
- Measurement conditions
- 32°C · 80%relative humidity
- Filtration
- Multi-stage + minerals
Series Signature
MEGHDOOT SIGNATUREA bespoke solution with a modular architecture that scales to meet any demand. Several units can be installed together on a rooftop or an open yard. Suited to campuses, office complexes, stadiums and industrial sites.
2,000 — 5,000L/day
Signature 2KSignature 2K2,000L/day22.0kWFactory · office complex · campus
- Daily output (maximum)
- 2,000L
- Electrical supply
- 440V 3ø
- Power consumption
- 22.0kW
- Energy per litre
- 0.26kWh/L
- Refrigerant
- R407C
- Tank capacity
- 700L
- Dimensions (L × W × H)
- 2700 × 1500 × 1650mm
- Floor area
- 4.05m²
- Weight
- 900kg
- Measurement conditions
- 32°C · 80%relative humidity
- Filtration
- Multi-stage + minerals
Signature 5KSignature 5K5,000L/day50.0kWIndustrial site · stadium · community
- Daily output (maximum)
- 5,000L
- Electrical supply
- 440V 3ø
- Power consumption
- 50.0kW
- Energy per litre
- 0.24kWh/L
- Refrigerant
- R407C
- Tank capacity
- 1000L
- Dimensions (L × W × H)
- 3300 × 2030 × 1900mm
- Floor area
- 6.7m²
- Weight
- 2,100kg
- Measurement conditions
- 32°C · 80%relative humidity
- Filtration
- Multi-stage + minerals
Technical specifications for every model
Source: the manufacturer’s official specification sheet. Note that energy efficiency improves as the model gets larger.
| Model | L/day | Supply | kW | kWh/L | Refrigerant | Tank | Dimensions (mm) | m² | Weight |
|---|---|---|---|---|---|---|---|---|---|
| Classic DLXPremium | 40 | 230V 1ø | 0.7 | 0.42 | R134a | 24 | 518 × 515 × 1475 | 0.27 | 102 |
| Classic PlusPremium | 60 | 230V 1ø | 1.1 | 0.44 | R134a | 25 | 700 × 550 × 950 | 0.39 | 100 |
| PremiumPremium | 150 | 230V 1ø | 2.0 | 0.32 | R407C | 60 | 960 × 790 × 1250 | 0.76 | 180 |
| Premium PlusPremium | 250 | 440V 3ø | 3.4 | 0.33 | R407C | 100 | 1000 × 850 × 1505 | 0.85 | 260 |
| MagnumMagnum | 500 | 440V 3ø | 5.5 | 0.26 | R407C | 300 | 1150 × 1820 × 1200 | 2.09 | 380 |
| Magnum PlusMagnum | 1,000 | 440V 3ø | 11.0 | 0.26 | R407C | 500 | 1200 × 1500 × 1650 | 1.8 | 450 |
| Signature 2KSignature | 2,000 | 440V 3ø | 22.0 | 0.26 | R407C | 700 | 2700 × 1500 × 1650 | 4.05 | 900 |
| Signature 5KSignature | 5,000 | 440V 3ø | 50.0 | 0.24 | R407C | 1000 | 3300 × 2030 × 1900 | 6.7 | 2,100 |
The “kWh/L” value is calculated by us (consumption × 24 ÷ daily output) to make efficiency comparable across models; it is not a figure declared by the manufacturer. Efficiency improves with size: from 0.42 on Classic DLX to 0.24 on Signature 5K.
Every figure is measured at 32°C and 80% relative humidity — the conditions that prevail in Qatar for most months of the year. The output expected at your site specifically is calculated in the site study and delivered in writing with the quotation.
What every model has in common
A difference in capacity is not a difference in principle. These characteristics are identical across all eight models.
Generation and purification in one system
The system depends on no existing water source — it generates water from air and purifies it in a single cycle, with no well and no mains connection.
Multi-stage filtration
Every model carries a multi-level filtration system and treatment configured to the client’s requirements, followed by the return of essential minerals.
Automatic stop when full
The unit stops itself when the tank is full and restarts as the level drops — no waste and no daily intervention.
Efficiency improves with capacity
Energy per litre falls as the model gets larger: from 0.44 kilowatt-hours per litre down to 0.24.
- ISO 9001:2015
- STQC
- GeM
- Ariba
These are the manufacturer’s certifications for the MEGHDOOT range, not Aqua Mist’s own. Copies are included in the technical file supplied with a site study request.
Which model suits your site?
Do not choose by instinct. The site study measures your actual consumption and the humidity and temperature conditions at your site, and ends with a recommended model and a detailed quotation covering installation, warranty and cost per litre.
